Dinghua PCB Xray machine DH-X7 is a high-precision testing system used to inspect the internal structure of electronic components and assemblies without causing any damage. It uses X-ray imaging technology to penetrate materials and create detailed internal images, allowing operators to see hidden defects that are invisible to the naked eye.

Non-destructive X-ray counting of SMD components
Fast and automatic counting for reels and sealed packages
High-resolution imaging for precise component detection
Supports reels, trays, and tube packaging
Improves inventory accuracy and reduces manual effort

Product Description Product Specification Products Applications Products Principle & Safety

Previous Next

Firstly, place the material in a position where it can be exposed to X-rays in the machine. When X-rays pass through the material (meaning those chips, smd components), the density and thickness of the material will affect the absorption of X-rays, and this difference is converted into an electrical signal. These electrical signals are then converted into digital signals and transmitted to a computer system for processing.

The computer system calculates the quantity of materials based on these signals, if the machine is online, it will controls the material conveying device and packaging device to transport the materials to the designated location and package them; if the machine is offline, it will just automatically print labels, you need to take reels/trays from SMD reel couter machine’s drawer for sticking labels.

Then, these materials can be recognized by scaning its barcodes,QR or directly reading its number on labels, which make management, production or inventory much more convenient and simple.

Power supply	100~230V 50/60Hz 17~7A
Rated power	1.7KW
Counting time	7 seconds for 4 reels inspecting together
Max reel	17 inches or 43cm
Min reel	3 inches or 7.6cm
Accuracy	99.98%
Components	including 01005 0201 0402 0603 0805 1005 1206 1210 1812 2010 2512
Label	64(LW)cm. number, barcode or QR
Dimension	1500× 900×1950mm
Net weight	505kg

Accuracy – Human error is eliminated by counting parts with a component counting machine instead of a small counter. X-ray imaging allows precise counting of each component.
Managing Inventory – Knowing exactly how many components are in each reel allows for better inventory management. Inventory levels can be accurately tracked
High efficiency – component counting machine, rapidly counting tens of thousands of parts in seconds, far faster than using a small counter, improves workflow and productivity.
Improved Productivity – With increased speed, accuracy, and efficiency, the SMD component counter machine significantly improves the productivity of facilities handling large quantities of electronic components.

Products principle

The basic principle of the X-ray counting machine is to use the penetrating power of X-rays. When X-rays pass through a test object, materials with different densities and compositions absorb the X-rays to different degrees. This absorption difference is converted into an image, and the machine’s artificial intelligence calculates the amount of material.

Products safety

That SMD reel counter machines were detected resulted in 0.18 µSv/hr, 1 cm from surface, which meets all international standards; in fact, the International standard is must be less than 0.5µSv/hr.
